202WPSERIES
3/4/5-pole, 3A, simple lock connector with 9 mm (OD) plug and 8.5 mm (OD) receptacle. Locking system with click feeling. Relaying type and screw lock type also available. Waterproof rating IP67.
| Waterproofness | Locking method |
|---|---|
| Waterproof(IP67) | Screw lockSimple lock |
| Current capacity | Number of poles |
|---|---|
| 3A | 345 |
Compatible cable diameter
φ3.5 / φ4.0
External dimensions may vary depending on the compatible cable diameter.
Coupling surface (female)
External dimensions(mm)
Cable specification
| 3-conductor cable | |
|---|---|
| Core wire | AWG23 |
| Shield type | − |
| Outer diameter(mm) | φ4.0 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 75.2Ω/km |
| Type | TZ-913 |
| Red/White/Black | |
| 3-conductor, fully shielded cable | |
|---|---|
| Core wire | AWG23 |
| Shield type | horizontal winding |
| Outer diameter(mm) | φ4.2 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 75.2Ω/km |
| Type | TZ-914 |
| Red/White/Black | |
| 4-conductor cable | |
|---|---|
| Core wire | AWG24 |
| Shield type | − |
| Outer diameter(mm) | φ4.0 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 88Ω/km |
| Type | TZ-921 |
| Red/White/Black/Yellow | |
*We can modify our connectors to fit cables other than those listed above (supplied or newly manufactured).
