220WPSERIES
16-pole, 1A, one-touch lock connector with 12.4 mm (OD) plug and 12 mm (OD) receptacle. Relaying type also available. Waterproof rating IP67.
![](https://www.witco.co.jp/wp2/wp-content/uploads/2022/04/36250369a977ba1893f8859265706c3d.jpg)
Waterproofness | Locking method |
---|---|
Waterproof(IP67) | One-touch lock |
Current capacity | Number of poles |
---|---|
1A | 16 |
Compatible cable diameter
φ5.0 / φ6.0
External dimensions may vary depending on the compatible cable diameter.
Coupling surface (female)
![](https://www.witco.co.jp/wp2/wp-content/uploads/2022/04/faf9a79c91c081b4664d5a8b00765a75.png)
External dimensions(mm)
![](https://www.witco.co.jp/wp2/wp-content/uploads/2022/12/b625e6e1c4c38a3bf4af574c09b2590b.png)
Cable specification
16-conductor, fully shielded cable | |
---|---|
Core wire | AWG28 |
Shield type | horizontal winding |
Outer diameter(mm) | φ6.0 |
Withstand voltage | AC500V/1minute |
Insulation resistance | 5MΩ・km |
Conductor resistance | 228Ω/km |
Type | TZ-937 |
Red/White/Blue/Black/Green/Orange/Purple/Yellow/Gray/Brown (White/Black)/(White/Red)/(White/Yellow) (White/Blue)/(White/Purple)/(White/Green) |
*We can modify our connectors to fit cables other than those listed above (supplied or newly manufactured).
