Witco of Jupiter Dentsu Co., Ltd.


The ultimate blind-mate connector
The roll-in connector is the world's first connector that does not require keying.
It is a round connector that mates no matter which angle you insert the plug.
One action is all it takes to align the plug tip with the socket and lock it in place.

Waterproofness Locking method
Non-waterproof Simple lock
Current capacity Number of poles
1A 6

Compatible cable diameter


External dimensions may vary depending on the compatible cable diameter.

Coupling surface (female)

External dimensions(mm)

Cable specification

5-conductor, fully shielded cable
Core wireAWG28
Shield typehorizontal winding
Outer diameter(mm)φ4.1
Withstand voltageAC500V/1 minute
Insulation resistance5MΩ・km
Conductor resistance237Ω/km

Contact us using this form to place an order for connectors or to require modifications to standard connectors.
