81SERIES
2/3/4-pole, 5A, one-touch lock connector with 10 mm (OD) plug and 10 mm (OD) receptacle. Relaying type also available.
| Waterproofness | Locking method |
|---|---|
| Non-waterproof | One-touch lock |
| Current capacity | Number of poles |
|---|---|
| 5A | 234 |
Compatible cable diameter
φ4.0
External dimensions may vary depending on the compatible cable diameter.
Coupling surface (female)
External dimensions(mm)
Cable specification
| 3-conductor, fully shielded cable | |
|---|---|
| Core wire | AWG23 |
| Shield type | − |
| Outer diameter(mm) | φ4.0 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 75.2Ω/km |
| Type | TZ-913 |
| Red/White/Black | |
| 3-conductor, fully shielded cable | |
|---|---|
| Core wire | AWG23 |
| Shield type | horizontal winding |
| Outer diameter(mm) | φ4.2 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 75.2Ω/km |
| Type | TG-914 |
| Red/White/Black | |
| 4-conductor cable | |
|---|---|
| Core wire | AWG24 |
| Shield type | − |
| Outer diameter(mm) | φ4.0 |
| Withstand voltage | AC500V/1minute |
| Insulation resistance | 5MΩ・km |
| Conductor resistance | 88Ω/km |
| Type | TZ-821 |
| Red/White/Blue/Black/Green/Orange/Purple/Yellow/Gray/Brown | |
*We can modify our connectors to fit cables other than those listed above (supplied or newly manufactured).
